Rubber Stopper Details
| SIZE # |
(diam.) (mm) TOP |
(diam.) (mm) BOTTOM |
(mm) LENGTH |
(diam.) (inches) TOP |
(diam.) (inches) BOTTOM |
(inches) LENGTH |
SOLID PART # |
1-HOLE PART # |
| 000 | 12 | 9 | 18 | .472" | .354" | .709" | 3730101 | 3731101 |
| 00 | 15 | 10 | 25 | .591" | .400" | .955" | 3730102 | 3731102 |
| 0 | 17 | 13 | 25 | .669" | .512" | .984" | 3730103 | 3731103 |
| 1 | 19 | 14 | 25 | .748" | .551" | .984" | 3730104 | 3731104 |
| 2 | 20 | 16 | 25 | .787" | .630" | .984" | 3730105 | 3731105 |
| 3 | 24 | 18 | 25 | .945" | .709" | .984" | 3730106 | 3731106 |
| 4 | 26 | 20 | 25 | 1.024" | .787" | .984" | 3730107 | 3731107 |
| 5 | 27 | 23 | 25 | 1.063" | .906" | .984" | 3730108 | 3731108 |
| 5½ | 28 | 24 | 25 | 1.102" | .945" | .984" | 3730109 | 3731109 |
| 6 | 32 | 26 | 25 | 1.260" | 1.024" | .984" | 3730110 | 3731110 |
| 6½ | 34 | 27 | 25 | 1.339" | 1.063" | .984" | 3730111 | 3731111 |
| 7 | 37 | 30 | 25 | 1.457" | 1.181" | .984" | 3730112 | 3731112 |
| 7½ | 39 | 31 | 25 | 1.535" | 1.220" | .984" | 3730113 | 3731113 |
| 8 | 41 | 33 | 25 | 1.614" | 1.299" | .984" | 3730114 | 3731114 |
| 8½ | 43 | 36 | 25 | 1.693" | 1.417" | .984" | 3730115 | 3731115 |
| 9 | 45 | 37 | 25 | 1.772" | 1.457" | .984" | 3730116 | 3731116 |
| 9½ | 46 | 38 | 25 | 1.811" | 1.496" | .984" | 3730217 | 3731217 |
| 10 | 50 | 42 | 25 | 1.969" | 1.654" | .984" | 3730220 | 3731220 |
| 10½ | 53 | 45 | 25 | 2.087" | 1.772" | .984" | 3730121 | 3731121 |
| 11 | 56 | 48 | 25 | 2.205" | 1.890" | .984" | 3730119 | 3731119 |
| 11½ | 63 | 50 | 25 | 2.480" | 1.969" | .984" | 3730122 | 3731122 |
| 12 | 64 | 54 | 25 | 2.520" | 2.126" | .984" | 3730120 | |
| 13 | 68 | 58 | 25 | 2.677" | 2.283" | .984" | 3730123 | |
| 13½ | 75 | 62 | 35 | 2.953" | 2.441" | 1.378" | 3730124 | |
| 14 | 90 | 75 | 39 | 3.543" | 2.953" | 1.535" | 3730125 | |
| 15 | 103 | 83 | 39 | 4.055" | 3.268" | 1.535" | 3730126 |
